Description

ER-078474

Manual 3-jaw concentric chuck diameter 125 mm

on die-plate pallet PM128 Precise

Version

Manual 3-jaw concentric chuck diameter 125 mm. Central clamping area 3-53 mm. Body made of cast metal. High degree of concentricity according to DIN 6386. Includes 3 hardened drilling jaws (stepped on the outside), 3 hardened turning jaws (stepped on the inside), 1 wrench.

Note

Max. speed 4,000 min-1.

Application

As adapter chuck in the die-plate chuck PM128 II AirDock.

Product Labels

• Manual operation
• For EDM sinking
• For chip-removing processes
