Description

ER-078473

ITS Chuck 100 P

on die-plate pallet PM128 Precise

Version

Hardened steel.

Clamping power

ITS Chuck 100 P: 6,000 N.

Connections

At the rear, to die-plate PM128.

Operation

Through AirDock valves. With compressed-air gun, control unit or through the machine control unit.

Application

As adapter chuck in the die-plate chuck PM 128 II AirDock. To accommodate electrode holders, pallets diameter 115, diameter 148, PM56, PM60 and PM85 Precise.

Product Labels

• Operate with compressed air jet
• Operate with manual control unit
• Operate with electropneumatic control unit
• Suited for automatic operation
• For EDM sinking
• For chip-removing processes
