Description

ER-068697

Manual 3-jaw concentric chuck diameter 140 mm

on pallet diameter 148 G

Version

Manually operated three-jaw chuck diameter140mm. Central clamping range 3-53mm. Body made of steel. High concentric accuracy according to DIN 6386. Fitted to pallet diameter 148 G. Including 3 hardened drilling jaws (outward stepped), 3 hardened turning jaws (inward stepped) and 1 wrench.

Please note

Max. speed 5,000 min-1.

Application

In combination with EROWA chucks on lathes, round tables, dividing heads, etc.

Spare parts

Block jaws, soft, for three-jaw chuck, set of 3, size 140mm.

Product Labels

• Manual operation
• Suited for automatic operation
• Handling with EROWA Robot gripper 148
• For EDM sinking
• For chip-removing processes
